AGL Series
Straight Column Type Four-points eccenttric press machine
AGL30T~125T
Standard Configuration
- Electric automatic lubricating device
- Electric slide adjusting device
- Electric die height indicator
- I slide and die balancing device
- Electronic cam control display
- Read from the brake performance monitoring device
- Static SPM display function
- Repair instructions function
- The air source socket
- Air blowing device
- Two degree drop protection device
- Detecting device
- Main motor reversal device
- Electronic trip counter
- Pre cut counter
- Preset counter
- Power socket
- Independent control box
- Operating platform
- Base plate and the bolt
- Maintenance tool box
- Operating instructions
Technical Parameters
Knakal Series
| Model | AGL-30 | AGL-40 | AGL-60 | AGL-80 | AGL-125 | AGL-200 |
|---|---|---|---|---|---|---|
| Capacity (Ton) | 30 | 40 | 60 | 80 | 125 | 200 |
| Stroke (mm) | 16, 20, 25, 30 | 16, 20, 25, 30 | 20, 25, 30, 40 | 20, 25, 30, 40 | 25, 32, 36 | 32, 36 |
| Stroke per minute (S.p.m) | 200-1250, 200-1050, 200-900 | 180-1000, 180-900, 180-850, 180-800 | 100-750, 100-650, 100-550 | 120-600, 120-550, 120-500, 120-450 | 400, 370, 350 | 370, 350 |
| max Die height (mm) | 190-240 | 190-240 | 220-300 | 240-320 | 270-350 | 270-350 |
| Slide adjustment (mm) | 50 | 50 | 80 | 80 | 80 | 80 |
| Area of slide (mm) | 600×300 | 750×340 | 1030×500 | 1380×580 | 1480×600 | 1480×600 |
| Area of bolster (mm) | 600×400 | 750×500 | 1100×600 | 1500×800 | 1600×900 | 1600×900 |
| thickness (mm) | 90 | 120 | 140 | 160 | 180 | 180 |
| Opening size of bolster (mm) | 400x350x60 | 600x500x100 | 800x700x100 | 1050x900x150 | 1050x900x150 | 1050x900x150 |
| Hole Size (mm) | 400×100 | 560×120 | 840×120 | 1200×160 | 1300×160 | 1300×160 |
| Main Motor (Kw) | 11x4P | 15x4P | 22x4P | 30x4P | 37x4P | 37x4P |
| Max.weight of upper die (kg) | MAX80 | MAX150-155 | MAX450 | MAX500 | MAX600 | MAX600 |
| Total weight (kg) | 6500 | 8000 | 14000 | 22000 | 33000 | 33000 |
